DESCRIPTION

LONG LIVE AERO

It’s hard to beat the sensation of power that comes from a great aero bike. What rider is ambivalent about a machine that is designed to give back free watts? Is there a competitor who doesn’t grasp every last advantage in the battle for speed? Orca Aero delivers these prizes – along with the willingness to go all-out, all day, without hesitation. Long live the bike that balances the emotional and rational desires inside each of us – Long live Aero.

HOW WE MADE IT

In professional cycling, partnerships matter, and the right combination can distinguish a good team from a great one, turning near misses into podium finishes. See the first steps of how Orbea and Lotto Dstny joined forces in the latest video.

PERFECT BALANCE

Historically, considering only the three design factors of aerodynamics, stiffness, and weight rarely yields dramatic improvement. Big gains in one area always compromise one or both of the others. The key to building the best aero road bike is finding the balance of these targets and identifying additional performance factors that allow the rider to increase efficiency.

AERODYNAMICS

Aligning the frame with the airflow, optimizing cross-sections, smoothing transitions, and myriad other improvements mean a big reduction in drag. Slipping effortlessly through the air, that instant feedback of a world-class aero bike. There is no better feeling.

POWER TRANSMISSION

The large majority of torsional and lateral loads are handled by the lower spine of the frame. A frame which is stiff in the right places means direct power transmission to the rear wheel.

BALANCED HANDLING

One of the most important points to consider when determining geometry is that the bike must be easy to ride. Going fast isn’t just a byproduct of good aerodynamics; it requires precise control over the bike.

SUPERIOR ERGONOMICS

Our all-new OC Cockpit has been designed for a perfect balance of aerodynamics, stiffness to weight, and ergonomics.

OQUO WHEELS

Orca Aero is available with OQUO’s Performance range, which focuses on weight and aerodynamics for modern, high-performance road bikes. With a choice of deeper, drag-reducing profiles, you can configure your perfect speed machine.

SPECIFICATIONS

FRAME

Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.

FORK

Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.

STEERER TUBE

FSA 1-1/2" Integrated Aluminium Cup

DRIVETRAIN

CRANKSET

Shimano 105 R7100 36x52t with left side 4iiii Powermeter

SHIFTERS

Shimano Di2 R7170

CASSETTE

Shimano 105 R7100 11-34t 12-Speed

REAR DERAILLEUR

Shimano 105 Di2 R7150

FRONT DERAILLEUR

Shimano 105 Di2 R7150

CHAIN

Shimano M6100

COCKPIT

HANDLEBAR

OC Road Aero RA11 Carbon, Reach 80, Drop 125

STEM

OC Road Performance RP10, -8º

BRAKES

Shimano R7170 Hydraulic Disc

BRAKES CONFIGURATION

N/A

WHEELS

Oquo Road Performance RP45TEAM

TYRES

Vittoria Corsa N.Ext G2.0 Foldable 700x28c

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Lite

REAR WHEEL AXLE

Orbea Thru Axle 12x142mm M12x2 P1 Lite

COMPONENTS

SEATPOST

OC Road Aero RA10 Carbon, SB0/25, w/Micro tilt adjustment

SADDLE

Prologo Scratch-M5 Pas T2.0 size 140mm

ACCESSORIES

HANDLEBAR TAPE

Orbea Anti-Slippery/Shock Proof

HYDRATION

OC Aero Bottle RA10 (550ml) + Carbon Cage Kit RA10

STORAGE

OC Aero Toolbox TB01PP
