DESCRIPTION

PRAISE THE LIGHT

Orca isn’t just light. It is 6.7kg of climbing technology designed to change how you reach the top.

The feeling of a bike this light and efficient is unbeatable, and this instant acceleration, vibration absorption, and responsive handling come from a frame which knows where it needs to be light and where it needs to be stiff. Welcome the ultimate climbing machine!

DOMINATE THE CLIMBS

Achieving Orca´s light weight required many marginal gains, focusing on the details and using the best materials across the range. Considering the bike as a package means working with component and wheel designers right from the start to optimize stiffness and weight.

RIGID IN ALL THE RIGHT PLACES

But having the lightest bike is worth nothing if it isn’t stiff and efficient. When we designed Orca, we started with a target rigidity to ensure that even the strongest climbers could be sure of efficient power transmission. Then we designed Orca to be as light as possible without compromising that number.

THE FEEL OF THE FREEDOM

There is indeed just something special about the feel of a lightweight bike. We love the instant acceleration when you stamp on the pedals and the responsive, agile handling as you carve through the turns.

NO TRADE-OFFS

Our clever frame design means that stiff doesn't have to be uncomfortable. Rounder frame sections help reduce vibrations, saving energy on longer rides and offering you an advantage on that final climb. Wider clearance allows for tires of up to 32mm - maximizing traction and compliance.

PERFORMANCE DESIGN

Orca is built on our understanding of performance and design, reflecting our belief that bikes should look great and ride better. Orca’s minimal, timeless lines give it its distinctive style and cover some very modern technology.

SPECIFICATIONS

FRAMESET

FRAME

Orbea Orca carbon OMR 2024, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.

FORK

Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.

STEERER TUBE

FSA 1-1/2" Integrated Aluminium Cup

DRIVETRAIN

CRANKSET

Shimano 105 R7100 34x50t

SHIFTERS

Shimano Di2 R7170

CASSETTE

Shimano 105 R7100 11-34t 12-Speed

REAR DERAILLEUR

Shimano 105 Di2 R7150

FRONT DERAILLEUR

Shimano 105 Di2 R7150

CHAIN

Shimano M6100

COCKPIT

HANDLEBAR

OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125

STEM

OC Road Performance RP22, -5º

BRAKES

Shimano R7170 Hydraulic Disc

BRAKES CONFIGURATION

N/A

WHEELS

Oquo Road Performance RP35TEAM

TYRES

Vittoria Corsa N.Ext G2.0 Foldable 700x28c

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Hollow

REAR WHEEL AXLE

Orbea Thru Axle 12x142mm M12x2 P1 Hollow

COMPONENTS

SEATPOST

SP 0.2 Carbon, 27.2mm, Setback 20

SADDLE

Fizik Aliante R5

ACCESSORIES

HANDLEBAR TAPE

Orbea Anti-Slippery/Shock Proof

SIZE GUIDE

Size	Height (cm)
47	155-160
49	160-166
51	167-172
53	173-179
55	180-185
57	186-191
60	192-207
