DESCRIPTION

RIDING WITHIN REACH

Grab your Avant and fill your bottles before rolling out on your afternoon ride. No other machine can better help you enjoy the exhilaration of road cycling. The speed, freedom, and the views offered by quiet roads are all included free with every Avant - and you love it.

FORK

Carbon.

MATERIAL

Aluminum.

ROUTING

Internal Cable Routing.

ICR Plus – Internal Cable Routing is carefully guided along the best path under the stem and through the head tube, with no rub or rattle, and is optimized for both traditional and electronic shifting systems. Proprietary headset spacers smooth airflow and offer easy adjustment.

HIGH POLISH

The new Avant receives the same level of design attention as our carbon frames - The tubes are butted and hydroformed with smooth, polished welds to match the dramatic look of the monocoque frame.

AVANT CARBON FORK

The carbon layup and shaping of the Avant fork offers the best combination of elasticity, tire clearance, and torsional stiffness. The fork legs sport integrated fender mounts and ample tire clearance for even more versatility.

REGISTER FOR YOUR WARRANTY AND BENEFITS

LIFETIME WARRANTY

We offer a lifetime warranty on your bike frame once the legal warranty period has expired.

ACCIDENT POLICY

If your bike cracks or breaks due to external factors, we’ll provide you with a discount for a similar new frame.

EXCLUSIVE BENEFITS

You get access to exclusive contests and prizes and have priority access to products and promotions.

SPECIFICATIONS

FRAME

Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system.

FORK

Orbea carbon 2021, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.

HEADSET

Acros Alloy 1-1/2" Internal Cable Routing.

CRANKSET

Shimano Claris R2000 34x50t.

SHIFTERS

Shimano Claris ST-R2000.

CASSETTE

Shimano HG50 11-32t 8-Speed.

REAR DERAILLEUR

Shimano Claris RD-R2000-GS.

FRONT DERAILLEUR

Shimano Claris FD-R2000-F.

CHAIN

KMC X8.

HANDLEBAR

OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125.

STEM

OC Road Performance RP21, -6º.

BRAKES

Jagwire RideRever Mechanical Disc.

WHEELS

Alloy, Tubeless, 700c, 19c, 28H.

TYRES

Vittoria Zafiro V Rigid bead 700x28c.

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Solid.

REAR WHEEL AXLE

Orbea Thru Axle 12x142mm M12x2 P1 Solid.

SEATPOST

Alloy, 27.2mm, Setback 20.

SADDLE

Fizik Aliante R5.

HANDLEBAR TAPE

Orbea Eva.

SIZE GUIDE

Size	Height (cm)
47	155-160
49	160-166
51	167-172
53	173-179
55	180-185
57	186-191
60	192-207
