SPECIFICATIONS

FRAMESET

FRAME

Orbea Vibe Mid Bar Hydro 6061 Hydroform Aluminum 2021, ICR cable routing, Forged BB, 135x9 QR, Flat Mount disc, 700x45 maximum tire, 1" 1/2 semi head set, 41x86.5 Pressfit BB, carrier and fenders compatible.

FORK

Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximum tire, flat mount disc mount, Thru Axle 12x100mm, Long mudguards compatible.

DIRECTION

Acros Alloy 1-1/2" Internal Cable Routing

E-BIKE

BATTERY

Mahle 36V/6.9A 248Wh ANT+

RANGE EXTENDER

N/A

MOTOR

Mahle motor hub X35 Plus

DISPLAY

N/A

CHARGER

Mahle X35

REMOTE

Mahle iWoc TRIO

DRIVETRAIN

CRANKSET

CR 0.1, Forged alloy, 42t, w/Chainguard

SHIFTERS

Shimano SL-M315

CASSETTE

Shimano CS-HG400 11-40t 8-Speed

REAR DERAILLEUR

Shimano Acera M3020

CHAIN

KMC X8

COCKPIT

HANDLEBAR

Alloy, 31.8mm, Rise 12mm, 700mm

STEM

Alloy forged, -6º, ICR

BRAKES

BRAKES

Shimano MT200 Hydraulic Disc

WHEELS

WHEELS

Alloy, Tubeless, 700c, 21c, 32H

TYRES

Kenda K1052 700x45C Reflective type + puncture protection

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Hollow

ACCESSORIES

PEDALS

VP-537 Black

FRONT POSITION LIGHT

Front position light, on head tube, COB Led, On/Off, 60 Lumen, ECE50.

FRONT LIGHT

N/A

REAR LIGHT

Lezyne FENDER STVZO seatpost mounting 11 lumens

QUICK STAND

N/A

BELL

Knog OI Classic

COMPONENTS

SEATPOST

Alloy, 27.2mm, Setback 0, for integrated light

SADDLE

Selle Royal Lift 1404 HRN 266x170mm

We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

SIZE GUIDE

Size	Height (cm)
S	150-165
M	165-175
L	175-190
