Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system.
Orbea (S102) Avant H102
Orbea (S102) Avant H102
إنتهى من المخزن
DESCRIPTION
RIDING WITHIN REACH
Grab your Avant and fill your bottles before rolling out on your afternoon ride. No other machine can better help you enjoy the exhilaration of road cycling. The speed, freedom and the views offered by quiet roads are all included free with every Avant - and you love it.
ICR PLUS
Internal Cable Routing is carefully guided along the best path under the stem and through the head tube, with no rub or rattle, and is optimized for both traditional and electronic shifting systems. Proprietary headset spacers smooth airflow and offer easy adjustment.
HIGH POLISH
The new Avant receives the same level of design attention as our carbon frames - The tubes are butted and hydroformed with smooth, polished welds to match the dramatic look of the monocoque frame.
AVANT CARBON FORK
The carbon layup and shaping of the Avant fork offers the best combination of elasticity, tire clearance and torsional stiffness. The fork legs sport integrated fender mounts and ample tire clearance for even more versatility.
SPECIFICATION
Frameset
Orbea Avant Hydro 2025, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
FSA 1-1/2" Integrated Aluminium Cup
Drivetrain
FSA Omega Megaexo 34x50t
Shimano Tiagra ST-4700
Sun Race CSMS1 11-34t 10-Speed
Shimano Tiagra 4700 GS
Shimano Tiagra 4700
KMC X10
Cockpit
OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125
OC Road Performance RP22, -5º
Brakes
Jagwire RideRever Mechanical Disc
Wheels
Alloy, Tubeless, 700c, 19c, 28H
Vittoria Zafiro V Rigid bead 700x28c
Orbea Thru Axle 12x100mm M12x2 P1 Solid
Orbea Thru Axle 12x142mm M12x2 P1 Solid inner threaded
Components
SP 0.6, Alloy, 27.2mm, Setback 20
Fizik Aliante R5
Accessories
Orbea Eva
OC Toolbox TB03PP
We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.
