SPECIFICATIONS

FRAME

Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1.5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27.2mm, MMS system.

FORK

Orbea carbon 2021, 1-1/8" - 1.5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.

DIRECTION

Acros Alloy 1-1/2" Internal Cable Routing.

CRANKSET

FSA Omega Megaexo 34x50t.

SHIFTERS

Shimano Tiagra ST-4700.

CASSSETTE

Sun Race CSMS1 11-34t 10-Speed.

REAR DERAILLEUR

Shimano Tiagra 4700 GS.

FRONT DERAILLEUR

Shimano Tiagra 4700.

CHAIN

KMC X10.

HANDLEBAR

OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125.

STEM

OC Road Performance RP21, -6º.

BRAKES

Jagwire RideRever Mechanical Disc.

WHEELS

Alloy, Tubeless, 700c, 19c, 28H.

TYRES

Vittoria Zafiro V Rigid bead 700x28c.

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Solid.

REAR WHEEL AXLE

Orbea Thru Axle 12x142mm M12x2 P1 Solid.

COMPONENTS

SEATPOST

Alloy, 27.2mm, Setback 20.

SADDLE

Fizik Aliante R5.

HANDLEBAR TAPE

Orbea Eva.
